Chongqing Cummins Open Type 220KW Generator Set

  • Official guide price: 116900 Rise
  • Engine model: MTA11-G2A
  • Fuel consumption: 200 /KW.h
  • Decibel of noise: 105 dB/1m
  • *Cummins patented PT fuel system ultra-high injection pressure ensures good atomization and full combustion of the engine.
  • *igh efficiency Holset exhaust gas turbocharger can ensure more sufficient intake improve engine efficiency further improve combustion and reduce engine specific fuel consumption.
  • *The cylinder block and cylinder head adopt built-in pressure lubricating oil channel which has compact structure and low failure rate.
  • *Cylinder head: four valves per cylinder optimized air / fuel mixture ratio effectively improve combustion and emissions; one cover for each cylinder convenient maintenance.
  • Product Detail

    Product parameters

  • Pre:Chongqing Cummins Open Type 200KW Generator Set
  • Next:Chongqing Cummins Open Type 250KW Generator Set

  • Generator set


    Length(mm)     2900 Engine brand     Chongqing Cummins
    Width(mm)     1863 Engine model     MTA11-G2A
    Height(mm)     1000 conventional power(KW)     220
    Total weight(kg)     2750 Reserve power(KW)     242
    Generator set model     VGF-CKKJ-220 Bore / stroke(mm)     125*147
    Rated power(KW)     220 Number of cylinders(piece)     6
    Actual power(KW)     209 Cylinder arrangement     In-line
    Full load fuel consumption(L)     35.2 Air intake and exhaust mode     Pressure boost
    Operational duration(Hour)     72 Speed control mode     Electronics
    Overhaul period(Hour)     3000 Rated fuel consumption(g/KW.h)     200
    Maintenance period(Hour)     500
    Life expectancy(Year)     20
    Noise(db)     105
    Starting mode     LCD button auto start
    Stop mode     LCD button auto stop
    Battery matching     100A*2
    Fuel tank(L)     500
    Protection function     Multi function and all-round protection
    Data display mode     LCD control panel digital display
    Reference price(RMB)     116900
